Specifications :
JIS G 3141 SPCC, SPCD, SPCEJIS G 3311 (Carbon, Alloy, Tool Steel)
ASTM A 109, ASTM A 366, ASTM A 619, ASTM A 620,
BS 1449/1, BSEN 10130-91, BSEN 10131-92
DIN 1624-87, DIN 1623/2-86
ISO 3474-86 (CR 1/2/3/4), ISO 5954-84(CRH 50/60/70),
Australia/N.Z. AS1595 NZCC NZCE, CA-2SE/CA55NE
According to JIS G3141
- SPCC : commercial quality is used for simple bending, forming or drawing, and has a widerange of uses for automotive, home appliances, building and civil works and base metals for
various kinds of prepainted steel products.
- SPCD : drawing quality is used for better than the commercial quality, it's high formability is
used for automotive panels, audio-visual equipment and other heating apparatuses.
- SPCE : deep drawing quality is used for the parts of complicated and severe forming products,
mainly for the automotive front panels and rear fenders
Dimensions :
Thickness : 0.15 – 3.00mmWidth : 30 – 1830mm
Length : Coil or sheets
Temper Grade :
as annealed, standard temper, 1/8 hard, 1/4 hard, 1/2 hard, full hardSurface Finish :
D (Dull Finish) - matt finish produced with a roll roughened its surface mechanically or chemicallyB (Bright Finish) - smooth finish produced with a roll finish its surface smoothly
Standard Packing :
Special care is given to prevent abrasion, rust and scratch during transportation and shipment,the procedures are illustrated as follows.
Unit weight is usually 2-5mt for sheet, 4-20mt for coils upon to the request
